| Part Number | NTD-2.8S240320M100A-C |
| Size | 2.8 inch |
| Resolution | 240xRGBx320 |
| Display Type | IPS(Normally Black), Transmissive TFT |
| Optimal View | Full View |
| Touchscreen | Capacitive with I2C Interface |
| Outline | 50.00(W)x69.20(H)x4.00(T) mm |
| Active Area | 43.20(W)x57.60(H) mm |
| Supply Voltage | 2.8V |
| Luminance | 230cd/m² (typ.) |
| Interface | MCU/SPI RGB |
| Pin Number | 50pins |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
