| Part Number | NTD-7.0S1024600R100C |
| Size | 7.0 inch |
| Resolution | 1024xRGBx600 |
| Display Type | IPS (Normally Black), Transmissive TFT |
| Optimal View | Full View |
| Touchscreen | None |
| Outline | 164.90(W)x100.00(H)x2.80(T) mm |
| Active Area | 154.21(W)x85.92(H) mm |
| Supply Voltage | 3.3 V |
| Luminance | 450cd/m² (typ.) |
| Interface | RGB |
| Pin Number | 40 pins |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
